Tips on STHJ Series A-Type Paddle Molasses Mixer

Congratulations on your purchase of Muyang Brand STHJ Series Type Paddle Molasses Mixer. Before you use it, there are something you should know about the operation manual and well know the safety points, different performances, requirements to installation and operation of this STHJ Series Paddle Mixer, so that you can expertly operate and use this machine, and create more benefits for you.

Firstly, a check on appearance should be made immediately when the equipment is transported to the destination. The mixing machine, which cannot be installed in predetermined place immediately, must be stored in a weatherproof place with facilities against external infringement in original packages. Secondly, startup and commissioning shall only be done by trained personnel. The operators shall know the instructions and operation regulations in provided documents before startup. Lastly, only professional persons can carry out maintenance and shall well know relevant stipulations in the documents provided by us. These stipulations are helpful for keeping the equipment in good condition, reducing wear and prolonging the service life.

The accident prevention rules in related documents must be well known and strictly obeyed. Muyang devotes to manufacturing feed machinery equipment according to the latest National Safety Standards and European Safety Standards (CE Certification Standards). Customers shall tell us the local safety rules before manufacturing. Additional expenses therefrom shall be borne by customers.

Muyang also provide you with steel silo project, you can visit our site and leave messages there.

Features of Thermal Insulation Silo

Muyang is well known for its great feed machinery and full production lines. Steel silo engineering, as Muyang’s important project, is with lower temperature, thus not likely to have condensation of moisture. Storing in a low temperature can increase the grain storage stability and keep the grain quality and prolong the safe. And the insulation silo is installing an insulation layer (polyurethane forth, rubber sponge, glass fiber etc.) on the outer wall, insulation silo can have a low fabrication cost compared to concrete silo.

Now, Muyang has accomplished over 100 storage projects in more than 20 provinces, cities and autonomous regions in China, including the fields of grain, edible oil, harbor, flour, brewage, chemical industry, fed, building material, environmental protection and so on. In recent years, Muyang activates in developing the international markets, and has won the international bids of storage projects many times, and its products are sold far to the countries such as Egypt, Saudi Arabia, Iran, Thailand ,India, Japan, Malaysia, Korea, Vietnam and other regions.

Successfully, Muyang has constructed processing grain silo projects for China Oil and Food stuffs Corporation, Xiwang Group, Yufeng Group of Hebei and other famous industries. In China, almost all large industries use Muyang’s product line and feed machines as Muyang is rank one in the field of feeding system.

Details on Muyang

Jiangsu Muyang Group is located in Yangzhou City, Jiangsu Province, one hour by train from Shanghai. Muyang was founded in 1967 and today is the world's third largest supplier of engineering and machinery for the agricultural industry.

Muyang's diversified products & services include: Structural Design & Engineering, Civil Engineering, Turnkey Structure, Steel Silo, Site Erection Management, Project Management, Cast Concrete Tunnel, Bridge, & Building Molds, Conveyors, Feed Machinery Design & Fabrication, Food Processing Machinery, Bulk Solids Handling, Waste Water Treatment Machinery, Factory Automation, Robotic Machinery Design & Manufacturing, Biomass Engineering, Machining & Turning, Protective Coatings.

Muyang employs over 4000 people in China and abroad, with offices or agents in 50 countries. Over 800 technical engineers are employed by Muyang who specialize in steel structure engineering, structural design, civil engineering, structural erection, machine building, heat treatment, feed science and technology, control & automation, computer sciences, animal nutrition, dust control, grain milling, chemical engineering, edible oil engineering and marketing.

Muyang is the seat for the National Technical Committee of Feed Machinery Standardization Administration of China and the Modern Feed Processing Equipment Research Center of Jiangsu province; a proven technological leader in the world feed industry.

The SJHA4A Double-circle Paddle Mixer

The SJHA4A Double-circle Paddle Mixer is widely used for mixing powdery and special granular materials in feed industry.

The SJHS4A Double-circle Paddle Mixer is a kind of horizontal batch mixer. With patented rotor structure, it is characterized by Short mixing period and high mixing homogeneity: The mixing homogeneity of material within 60~90S amounts to CV≤5%, reduce the mixing period and improve the production efficiency; (Methyl Violet Stain (GB/T5918) method is used to test the CV value of mixed product). Large variable range of filling factor: The Filling factor is between 0.4~1, applicable for mixing the materials with different specific gravity and granularity in various industries. The shaft seal adopts the unique sealing technology, reliable seal, no leakage and long service life.

The discharge gates adopt full-length opening structure, which contributes to fast discharge and little residues. The seal of discharge gates adopts the unique sealing technology, reliable seal and no leakage. Available of rise and fall type liquid application system is convenient and rapid for cleaning and replacing nozzles and can spray liquid evenly. With air-return mechanism, the pressure difference between inner and outer of the mixing machine can be well balanced when feeding or discharging.

Muyang PHGM200 Rice Extruder

Muyang PHGM200 rice extruder is mainly applicable for production of puffed rice, which is one of the main raw materials of paste like food product such as sesame soup and etc.

The extruder mainly consists of a belt pulley and a hood shield, a main motor, an extruding device, a cutting device, a disassembling tool, an extruder base, a lubricating oil-way and a motor base etc.

Materials with certain moisture enter the feed extruder and flow axially through being pushed by the screw; Due to the mechanical friction between the screw and materials, the machine cylinder and materials as well as the friction between material particles, the materials are intensively extruded, stirred and cut, so that they are further pulverized and homogenized.

Since the temperature rises along with the increasing pressure, the properties of materials change under conditions of high temperature, high pressure and high shear force, that is, powdery materials become a pasty mass, starch is gelatinized, protein is modified, fiber is partially degraded and fined, pathogenic bacteria are killed, hygienic indexes are improved and toxic substances are inactivated.

Under the action of great pressure difference, the pasty materials are expanded, dehydrated and cooled as soon as they sprayed out of the die holes. The porous expanded product is crisp with loose structure, fine in palatability and flavor. And it is cut to required form by a cutting device.

MUZL350T Type Pellet Mill

The serrated belt stepping drive system is adopted for MUZL350T pellet mill, which is characterized by ideal drive ratio, great driving moment, smooth rotation, high throughput, low noise, easy operation and maintenance.

This type of pelleting machine can be fitted with many kinds of ring dies with φ1.6~φ12 die holes and different thickness, and the user can select based on self-demand for achieving the optimum technical and economic efficiency.

The variable speed control motor is adopted for this machine type to feed material, equipped with overload protection device sand outside discharging mechanisms, the bypass gate can be opened automatically in case of overload of main motor.

It is available to select different type of conditioners as required, such as single-layer, double-layer, triple-layer and double-shaft differential conditioners.

To ensure safety, this pelleting machine shall be used in the areas with an altitude lower than 1000m, a temperature from -5℃to 40℃ and an air relative humidity from 30％to 95％. If the area does not conform to above conditions, please indicate specially when ordering.

This machine is specially used for feed processing, generally for processing powdery, flowable and easily pelleted materials. Do not use it for processing of food.

Muyang MNMP21A Vertical Iron Roll Rice Whitener

Muyang MNMP21A Vertical Iron Roll Rice Whitener is applicable for a rice processing plant with a daily capacity of 80～120 tons white rice and used for whitening thoroughly cleaned rice. In combination with Muyang MNML40 vertical emery roll rice whitener, the white rice with different whitening degrees can be produced, and good technological and economic results can be obtained.

The floated rice bran on rice surface can be removed by the Dampening Iron Roll Rice Whitener, thus a good surface smoothness of the white rice can be obtained for further polishing. Any usage beyond the scope of application like processing un-cleaned rice should not be regarded as an application related to the design purpose. The feed machinery manufacturer will not undertake the responsibility of any loss resulted here from.

The usage relevant to the design purpose refers to that the users should strictly follow the regulation sand instructions in aspects like installation, operation, inspection and maintenance given in the Operation Manual for usage of this feeding machine.



1 Stander: including base frame and operating gate
2 Bran suction device: including differential pressure gauge
3 Whitening chamber: including bearing assemble, screw head, iron roll, screen frame and rice screen etc.
4 Electric control: including ammeter, start and stop buttons, etc.
5 Discharge outlet: including pressure door, discharge spout, weight and pressure lever
6 Main driving device: including main motor, belt pulley and V-belt
7 Dampening system: including water pump and solenoid valve
8 Air jetting fan
9 Feeder device: including feed hopper and feeding screw

Brown rice husked by emery roll rice whitener is driven by horizontal feeding screw on the grinding machinery, and then enters into the bottom of whitening chamber, and is conveyed by screw head from top to bottom to the clearance between iron roll and rice screen. Here, brown rice moves upwards spirally along the iron roll surface. The rice grains can be milled and whitened by frictional action between the iron roll and rice grain, screen and rice grain as well as between rice grains.



The air flow on the grinding machine generated by the air jetting fan enters hollow shaft from upper side to lower side, and then pass through the materials layer from inside to outside, thus the material is cooled and the temperature of rice is reduced. In addition, the bran is forced to discharge from screen apertures rapidly and sucked out by bran suction fan under dual effects of aspiration system and jetting air flow.

Muyang SWLZ Series Automatic Feeder

Congratulations on your purchase of SWLZ Series Automatic Feeder. This feeder is a brand new intelligent feeding device for a hammer mill, and can be widely applicable for feeding different granular and powdery materials in cereal, oil, feed and food processing factories. Prior to use, please read through this Operation Manual and well know the safety points, different performances, requirements to installation and operation of this feeder, so that you can expertly operate and use this machine, and create more benefits for you.

Based on the working current value of a grinding machine and through changing the rotating speed of the frequency conversion motor and the opening of the feeding gate, the feeding amount of the feeder is controlled in real time, to make it fast enter the working state with full load and run stably under this state; A closed-loop control is used for its controller, so as to essentially guarantee the stable running of the grinding machinery motor, reduce the impact to the grinding machine and prolong the service life of the equipment.

A humanized man-machine interaction interface is used for the controller, the operation is simple and convenient, enabling workers' operating difficult to be lowered obviously; The current trend line makes the running situations of the grinding machines be clear at a glance; This feeder is adaptable for both powdery and granular materials; A shallow and long groove is used for the feeding roll, so as to reduce blocked materials in the groove; Both ends of housing are sealed with end covers, so as to prolong the service life of bearings with pedestal; An iron removal device and an impurity discharging hopper are set up near the material outlet, guaranteeing to provide clean material stream for the grinding machine.

SJHS4A Double-circle Paddle Mixer

Muyang double-circle paddle mixer is independently researched and designed by Muyang and wins international patent technologies. It has advantages of quick mixing time, high homogeneity and no residues. The SJHA4A Double-circle Paddle Mixer is widely used for mixing powdery and special granular materials in feed industry. With patented rotor structure, it is characterized by Short mixing period and high mixing homogeneity. The mixing homogeneity of material within 60~90S amounts to CV≤5%, reduce the mixing period and improve the production efficiency; (Methyl Violet Stain (GB/T5918) method is used to test the CV value of mixed product).

When you operate the mixing machine, you should notice some necessary tips as it is not so easy to be managed without any specifications.

The operation, checking and maintenance etc. of machine or equipment can only be carried out by the qualified professionals trained by Muyang. Whenever maintenance or repairing is to be done, the power must be cut off first so as to prevent the motor from accidental staring. All related employees should receive safety education, the enterprise management regulations of the enterprise should be observed.



The mixing machinery must not be used for the applications which are not in the application range. The safety marks must be kept clean and cannot be taken off or covered. The safety guards can never be dismounted, covered or overlapped willfully, and can never be opened until the machine has completely stopped. And the machine can only be started when these safety guards are in good order functionally.

The damaged parts must be repaired or replaced promptly. For transportation and handling, it is not allowed to damage the equipment by bundling. In case there is any machine damage or missing of parts found in transportation or handling, it should be reported to the management immediately. Before installation, all feed mixer parts must be kept in their original packages. The machine parts and packing boxes should be properly covered and stored in places sheltered from rain, sunning and damp. The permissible load of hoister should higher than the equipment weight. As hoisting, only the hoisting points assigned on the machine can be used; the hoisting ropes must be fixed correctly and reliably; and no one is allowed to be under the equipment being hoisted.

In installation, enough space should be reserved for future maintenance and replacement of the equipment.
